product attribute
| Host end interface: | SFF-8643 to 8087 Mini SAS |
| Device-end interface： | The SFF-8643 port is configured as 8i (8 channels) |
| length： | 0.5M 0.8M 1M |
| Support Agreement： | SAS 3.0(12Gbps),Compatible with the SAS 2.0 (6Gbps) protocol and also compatible with the SATA protocol |
| Main purpose： | Server upgrade, storage expansion, data center and enterprise network |
| Interface material： | Gold-plated stitches, resistant to wear and oxidation |
| Electrical characteristics: | a) Data speed: 12 Gbps |
| b) Wire gauge 30AWG | |
| c) Insertion and removal life: At least 250 cycles | |
| d) Insulation 100Ω | |
| e) Use high-frequency copper as the conductor | |
| application: | Server upgrade, storage expansion, data migration |
| Environmental standards: | RoHS Compliant |
application area
♦ Server Upgrade: When your server motherboard or RAID card has been upgraded to support the SFF-8643 (Mini SAS HD) interface, but still needs to connect to the old-style hard drive backplane or drive with the SFF-8087 (Mini SAS) interface.
♦ Storage expansion: Used for connecting different generations of disk cabinets or storage arrays.
♦ Data Center and Enterprise Network: In scenarios where high bandwidth and high-density connectivity are required, it helps achieve flexible system configuration and scalability.
Why Choose our Lungkay
LUNGKAY Electronics - Your exclusive expert for cable manufacturing design
- Reliable Quality: Expert design using phosphor bronze terminals and durable PBT housing ensures long-lasting performance.
- Strict Testing: Every assembly undergoes comprehensive testing to guarantee signal integrity and electrical performance.
- Full Customization: We offer complete OEM/ODM services for unique cable lengths, pinouts, and connector requirements.
