The Scsi Motherboard Mcr Slot Type Scsi 26 36 50 68P Female is a SCSI motherboard interconnect assembly built for storage backplanes and legacy server maintainance: crimp-and-idc terminations on 28 AWG conductors, keyed housings that prevent mis-mating, and shell grounding that holds signal integrity across the chassis. The 68P configuration matches standard backplane footprints.
| Specification | Standard build | Custom option |
|---|---|---|
| Conductor | 28 AWG, twisted pair | 26 AWG for power runs |
| Shielding | Overall foil + braid | Double braid on request |
| Length | Standard 0.3–1.0 m | Any length, MOQ per run |
| Compliance | RoHS, CE | UL style file on request |
Custom pin maps, lengths and bracket styles are produced to drawing; samples ship before production for pin-out verification. The SCSI family context and selection logic are covered in the Mini SAS and SCSI technical guide. Standards background: Parallel SCSI.
